Manticore 2.7.5 对比 Sphinx 3.1.1

已发布: Jan 28, 2019
自动翻译: Manticore 2.7.5 vs Sphinx 3.1.1

在这里我们对比测试了 Sphinx 3.0.2 和 Manticore 2.6.2。那是8个月前的事了,从那时起 Manticore 和 Sphinx 都有所变化。正如 Sphinx 3.0.3 发布公告所说,Sphinx 3.0.3 相比 3.0.2 速度提升了2倍,所以再做一次基准测试很有意思。这次让我们用真实数据集 - Hacker News 评论来测试。

基准测试在以下条件下进行:

Hacker News 精选评论数据集 2016年的 CSV 格式数据
操作系统: 16.04.4 LTS (Xenial Xerus), 内核: 4.15.0-30-generic
CPU: Intel(R) Xeon(R) CPU E3-1275 v5 @ 3.60GHz, 8核
64G 内存
HDD 硬盘
Docker 版本 17.05.0-ce, build 89658be
索引和 searchd 的基础镜像 - alpine:3.6
Manticore Search 在此环境下编译,Sphinx 二进制文件从官网下载因为没有开源代码可供编译
使用 stress-tester 做基准测试

Manticore 和 Sphinx 使用相同的配置:

source full
{
  type = csvpipe
  csvpipe_command = cat /root/hacker_news_comments.prepared.csv|grep -v line_number
  csvpipe_attr_uint = story_id
  csvpipe_attr_timestamp = story_time
  csvpipe_field = story_text
  csvpipe_field = story_author
  csvpipe_attr_uint = comment_id
  csvpipe_field = comment_text
  csvpipe_field = comment_author
  csvpipe_attr_uint = comment_ranking
  csvpipe_attr_uint = author_comment_count
  csvpipe_attr_uint = story_comment_count
}

index full
{
  path = /root/idx_full
  source = full
  html_strip = 1
  mlock = 1
}

searchd
{
  listen = 9306:mysql41
  query_log = /root/query.log
  log = /root/searchd.log
  pid_file = /root/searchd.pid
  binlog_path =
  qcache_max_bytes = 0
}

索引创建

索引创建耗时 Manticore 682秒, Sphinx 645秒:

Manticore:

indexing index 'full'...
collected 11654429 docs, 6198.6 MB
sorted 1115.7 Mhits, 100.0% done
total 11654429 docs, 6198580642 bytes
total <b>681.732 sec</b>, 9092389 bytes/sec, 17095.30 docs/sec
total 11676 reads, 1.811 sec, 452.6 kb/call avg, 0.1 msec/call avg
total 9431 writes, 4.878 sec, 1065.3 kb/call avg, 0.5 msec/call avg

Sphinx:

using config file '/root/manticore.conf'...
indexing index 'full'...
collected 11654429 docs, 6198.6 MB
sorted 1115.7 Mhits, 100.0% done
total 11654429 docs, 6.199 Gb
total <b>645.7 sec</b>, 9.600 Mb/sec, 18049 docs/sec

所以在这个数据集和索引方案下,Manticore 的索引速度比 Sphinx 慢 5.6%。

性能测试

测试前两个实例都进行了预热。索引大小相同且都完全在操作系统缓存中:

Manticore:

snikolaev@dev:~$ sudo ls -lah /var/lib/docker/volumes/4702617c7b0d970ba660514053706125fd88f2a4b7fce7222aab1f53fba2b56d/_data/
total 4.6G
drwx------ 2 root root 4.0K Jan 25 04:50 .
drwxr-xr-x 3 root root 4.0K Jan 25 04:43 ..
-rw-r--r-- 1 root root 362M Jan 25 03:51 idx_full.spa
-rw-r--r-- 1 root root 3.1G Jan 25 03:56 idx_full.spd
-rw-r--r-- 1 root root 27M Jan 25 03:56 idx_full.spe
-rw-r--r-- 1 root root 601 Jan 25 03:56 idx_full.sph
-rw-r--r-- 1 root root 6.3M Jan 25 03:56 idx_full.spi
-rw-r--r-- 1 root root 0 Jan 25 03:51 idx_full.spk
-rw------- 1 root root 0 Jan 25 04:50 idx_full.spl
-rw-r--r-- 1 root root 0 Jan 25 03:51 idx_full.spm
-rw-r--r-- 1 root root 1.1G Jan 25 03:56 idx_full.spp
-rw-r--r-- 1 root root 1 Jan 25 03:56 idx_full.sps
-rw-rw-r-- 1 root root 750 Jan 25 03:27 manticore.conf
lrwxrwxrwx 1 root root 11 Jan 25 03:57 query.log -> /dev/stdout
lrwxrwxrwx 1 root root 11 Jan 25 03:57 searchd.log -> /dev/stdout
-rw------- 1 root root 2 Jan 25 04:50 searchd.pid
snikolaev@dev:~$ sudo vmtouch /var/lib/docker/volumes/4702617c7b0d970ba660514053706125fd88f2a4b7fce7222aab1f53fba2b56d/_data/
vmtouch: WARNING: not following symbolic link /var/lib/docker/volumes/4702617c7b0d970ba660514053706125fd88f2a4b7fce7222aab1f53fba2b56d/_data/searchd.log
vmtouch: WARNING: not following symbolic link /var/lib/docker/volumes/4702617c7b0d970ba660514053706125fd88f2a4b7fce7222aab1f53fba2b56d/_data/query.log
Files: 12
Directories: 1
Resident Pages: 1190485/1190682 4G/4G 100%
Elapsed: 0.070337 seconds

Sphinx:

snikolaev@dev:~$ sudo ls -lah /var/lib/docker/volumes/0aa7c89baeaa4c1bd2c52d2fbffe6f05fde5f43243534d5725482a702a90fd5b/_data
total 4.6G
drwx------ 3 root root 4.0K Jan 25 04:50 .
drwxr-xr-x 3 root root 4.0K Jan 25 04:43 ..
-rw-r--r-- 1 root root 362M Jan 25 03:37 idx_full.spa
-rw-r--r-- 1 root root 3.1G Jan 25 03:41 idx_full.spd
-rw-r--r-- 1 root root 27M Jan 25 03:41 idx_full.spe
-rw-r--r-- 1 root root 648 Jan 25 03:41 idx_full.sph
-rw-r--r-- 1 root root 6.3M Jan 25 03:41 idx_full.spi
-rw-r--r-- 1 root root 8 Jan 25 03:37 idx_full.spj
-rw-r--r-- 1 root root 1.4M Jan 25 03:37 idx_full.spk
-rw------- 1 root root 0 Jan 25 04:50 idx_full.spl
-rw-r--r-- 1 root root 1.1G Jan 25 03:41 idx_full.spp
-rw-rw-r-- 1 root root 750 Jan 25 03:27 manticore.conf
lrwxrwxrwx 1 root root 11 Jan 25 03:42 query.log -> /dev/stdout
lrwxrwxrwx 1 root root 11 Jan 25 03:42 searchd.log -> /dev/stdout
-rw------- 1 root root 2 Jan 25 04:50 searchd.pid
drwxr-sr-x 8 root root 4.0K Jan 23 08:01 sphinx-3.1.1
snikolaev@dev:~$ sudo vmtouch /var/lib/docker/volumes/0aa7c89baeaa4c1bd2c52d2fbffe6f05fde5f43243534d5725482a702a90fd5b/_data
vmtouch: WARNING: not following symbolic link /var/lib/docker/volumes/0aa7c89baeaa4c1bd2c52d2fbffe6f05fde5f43243534d5725482a702a90fd5b/_data/searchd.log
vmtouch: WARNING: not following symbolic link /var/lib/docker/volumes/0aa7c89baeaa4c1bd2c52d2fbffe6f05fde5f43243534d5725482a702a90fd5b/_data/query.log
Files: 156
Directories: 18
Resident Pages: 1195648/1210212 4G/4G 98.8%
Elapsed: 0.075835 seconds

测试1 - 处理集合中前1000个词的时间

首先让我们运行一个简单的测试 - 找出包含集合中前1000个最常见词的文档需要多长时间:

for n in `head -1000 hn_top.txt|awk '{print $1}'`; do
mysql -P9306 -hhn_$engine -e "select * from full where match('@(comment_text,story_text,comment_author,story_author) $n') limit 10 option max_matches=1000" > /dev/null
done

结果是:Sphinx 32.9秒,Manticore 28.1秒。所以在这个测试中Manticore Search 比 Sphinx Search 快16.7%。
